Amiad Automatic filter fibreglass reinforced nylon 2" male thread 8bar 130micron 0,13 mm stainless steel 316 9-12VDC latch black/green type Mini Sigma On-line
Product number: 7028312
Manuals & drawings
Frequently bought together
Technical details
-
Backflush flow rate8,7 m³/h
-
Connectionmale thread
-
Filtration0,13 mm
-
Material filter elementstainless steel 316
-
Material sealEPDM
-
TypeMini Sigma On-line
-
Voltage9-12VDC latch
-
Materialfibreglass reinforced nylon
-
Length1096 mm
-
Pressure8 bar
-
Capacity30 m³/h
-
Backflush Outlet1 1/2 "
-
Colourblack/green
-
Size2"
-
Filter area0.12 m²
-
EAN4019305708333
-
Part number7028312
-
ManufacturerAmiad
Product description
The Amiad Mini Sigma for online installations.
The Amiad ADI-P 12VDC controller with a 2W-Latch solenoid allows the user to monitor and control the filter from the Amiad app on your mobile via Bluetooth.
The app will provide the following information:
-DP and flush cycle counters.
- Alerts (low/high pressures) and low battery.
- Reports and performance history data.
Self-cleaning cycle is trigged by an integrated DP switch which is initiated by: a Pre-set 0.5 signal from DP switch, a time interval or a manual start.
Flushing time of 10 seconds.
Delivered with 1.5'' flush valve.
